PUREVA NEO™: Large format PUR glue binder

Product Code: 701052
Availability: 2 - 3 weeks
Qty: + -


One Compact Machine for Hard & Soft Cover Books
using either PUR or EVA hot melt

The new Fastbind PUREVA NEO is the next evolutionary step resulting from years of experience in making the highest quality EVA binders.
The Fastbind PUREVA XT makes it possible for anyone to take advantage of the PUR Hot Melt quality with a remarkably low investment and cost. The versatility of the Fastbind PUREVA NEO can meet all of your perfect binding needs at a price unparalleled in the industry! Thanks to its integrated casing-in system, the PUREVA NEO produces both soft and hard cover books in many sizes and thickness! It also introduces a new interchangeable glue cartridge to easily change between PUR & EVA glues. The new PGO Microcut roughener & hot melt applicator improves the binding strength over other competing technologies!



New patented glue mechanism

With traditional PUR machines, maintenance can be expensive and time consuming, making it hard to ensure a reliable finishing process in order to meet deadlines. PUREVA NEO’s innovative glue mechanism is easily cleaned or even changed, thanks to economical glue cartridges making it possible to change from PUR to EVA in seconds. Electronic adjustable temperature control with single button operation when switching between glue types.
PUREVA NEO has also a totally new kind of rail mechanism for the glue applicator. The applicator glides effortlessly over the book block, with almost no resistance. The large handle is placed low in front of the applicator to further improve ease of use.

New PGO Microcut roughener for coated paper stocks

Fastbind PUREVA NEO features the new Fastbind PGO Microcut roughener. It provides an optimized cutting pattern that increases glue penetration for better binding strength. Unlike other spine rougheners that grind the spine creating lots of noise and dust, the PGO opens the paper grain with very little noise and almost no paper dust!



Easy to use

PUREVA NEO requires no set-up times or book format adjustments. It self adjusts for book thickness from 1 to 1000 pages*. It offers easy manual operation which along with the rugged construction means low maintenance and years of dependable use.
* depending on paper type

Specifications:

Production speed 1–3 books per minute
Min/max binding thickness 0.1–45 mm 0.1–1.9”
Max. binding length Up to 455 mm 17.9”
Min/Max. binding height 140 mm / 320 mm 5.5–12.5”
Max soft cover thickness** Up to 400 g/m2
Voltage (V) / Frequency (Hz) 220–240 / 50–60
Max. current 3.8 A
Machine dimensions (W x L x H) 107 x 60 x 64 cm 42 x 23 x 25”
Weight 90 kg 198 lbs
Standard tools Hard & Soft cover tool set
Approvals CE
* output rate depends on operator, selected cover and glue type
** depending on material properties
Product information as of July 2014 and is subject to change without notice.
